A Scanning Electron Microscope (SEM) is a microscope that produces high-resolution, 3D-like, topographic images of materials at nano-to-micro scales by scanning a focused electron beam across a conductive sample surface. Operating in a vacuum, it offers superior magnification (up to 300,000x+) and depth of field compared to light microscopes, with applications in materials science, biology, and forensics.
